| B/F系列产品 | ||||
| 1 法国品牌，军工品质 France brand,military quality 3 先进的机组安保系统 Advancde gen-sets security system 5 适合多种应用场景的结构/功能解决方案 Professional structure/function solution for varieties of scenarios | 2 行业先进的产品性能指标 Excellent product performance indicators leading industry 4 专业的发电机组应用集成能力 Professional application & integration capabilities for gen-sets 6 具备国内各类产品认证资质以及CE认证 Have kinds of domestic product certification and CE certification | |||
| 机组型号Gensets Model | WPG1650B7 | WPG1815B7 | WPG1925B7 | WPG2000B7 |
| 额定功率/容量(kW/kVA) Rated Power/Capacity | 1200/1500 | 1320/1650 | 1400/1750 | / |
| 备用功率/容量(kW/kVA) Standby Power/Capacity | 1320/1650 | 1452/1815 | 1540/1925 | 1500/1875 |
| 发动机型号Engine Model | 16M33D1573E310 | 16M33D1573E310 | 16M33D1650E310 | 16M33D1650E310 |
| 额定功率(kW)Rated Power | 1390 | 1430 | 1500 | 1500 |
| 备用功率（kW）Standby Power | 1527 | 1573 | 1650 | 1650 |
| 气缸数-缸径×行程(mm) Cylinder No.-Bore×Stroke | 16-150X185 | |||
| 排量（L）Displacement | 52.3 | |||
| 启动方式Starting Method | DC24V电启动 Electrical Starting | |||
| 调速方式Speed Governor | 电控ECU | |||
| 进气方式Intake Way | 增压中冷 Turbo & Inter-cooling | |||
| 机油容量(L)Oil Capacity | 180 | |||
| 冷却液容量（L） Coolant Capacity | 350 | |||
| 经济燃油消耗率(g/kW.h) Economic Fuel Consumption | 190 | |||
| 额定电压（V）Rated Voltage | 400/230 | |||
| 频率(Hz)Frequency | 50 | |||
| 额定电流(A)Rated Current | 2165 | 2382 | 2526 | 2706 |
| 额定功率因数Rated Factor | 0.8（滞后lag） | |||
| 相数及接法 Phase No.& Connection | 三相四线，星型接法 3P4W,Y Style Connection | |||
| 调压方式 Voltage Regulation Mode | 自动调压AVR | |||
